Feed Mixer

  • single shaft paddle mixer
  • single shaft paddle mixer
  • single shaft paddle mixer
  • single shaft paddle mixer
  • single shaft paddle mixer
single shaft paddle mixersingle shaft paddle mixersingle shaft paddle mixersingle shaft paddle mixersingle shaft paddle mixer

single shaft paddle mixer

  • Capacity: 250-3000kg per batch
  • Each batch mixing time: 30-120S
  • Power: 5.5/11/18.5/30/45kw
  • Application: Powder Feed Mixer
  • Product description: single shaft paddle mixer use for mixing animal feed raw materials. also can be make by SUS304 stainless steel . E-mail: info@astarmachine.com whatsapp: 0086 15178920906
  • INQUIRY

SSHJ series single shaft paddle mixer machine:



1. It is widely used in feed, food, chemical industry, chemical, fertilizer and industry for the mixing of powder, granular, flake, lump and other materials .

2. It has high mixing speed and short mixing period, mixing speed is 30-120 seconds per batch .

3. Mixing homogeneity is high, reaching 95% ( i.e. CV is less than 5%). Besides segregation won’t happen .

4. Mixing capacity is variable with large effective volume .

5. The bottom-type electric or pneumatic discharging system can assure fast material discharging and less residue wit door shaft chain mechanism .

6. The equipment of return air inlet can help avoid powder leakage, when fully meets the requirement of environment protection .

7. Compressed  air cleaning system can be equipped according to your actual need which will minimize the residue amount .

8. Special atomized spraying system customizable, the addition of molasses, oil and other material will be more homogeneous .

9. There are various machine types for your choice, including carbon steel, stainless steel, composite materials .etc .

Product technical parameters :

Item

Effective volume

Each batch loading

Each batch mixing time

Uniformity

Power

Model

(m3)

(kg)

(S)

(CV%)

(kw)

SSHJ0.5

0.5

250

30-120

5

5.5

SSHJ1

1

500

30-120

5

11

SSHJ2

2

1000

30-120

5

18.5

SSHJ4

4

2000

30-120

5

30

SSHJ6

6

3000

30-120

5

45

SSHJ series single shaft paddle mixer more detail photos:

inner is single shaft paddle mixer:



single shaft paddle mixer air cylinder connect device :


Single shaft paddle mixer more photos :


more information, pls contact with us freely.

whatsapp: 0086 15178920906

e-mail: info@astarmachine.com
